TITANIUM SUPPLIERS

Titanium Alloys

Grade 1

titanium suppliers Grade 1 titanium is the first of four commercially pure titanium grades. It is the softest and most ductile of these grades. It possesses the greatest formability, excellent corrosion resistance and high impact toughness.

Because of all these qualities, Grade 1 is the material of choice for any application where ease of formability is required and is commonly available as titanium plate and tubing. These include:

• Chemical processing
• Chlorate manufacturing
• Dimensional stable anodes
• Desalination
• Architecture
• Medical industry
• Marine industry
• Automotive parts
• Airframe structure

Grade 2

Grade 2 titanium is called the “workhorse” of the commercially pure titanium industry, thanks to its varied usability and wide availability. It shares many of the same qualities as Grade 1 titanium, but it is slightly stronger. Both are equally corrosion resistant.

This grade possesses good weldability, strength, ductility and formability. This makes Grade 2 titanium bar and sheet are the prime choice for many fields of applications:

• Architecture
• Power generation
• Medical industry
• Hydro-carbon processing
• Marine industry
• Exhaust pipe shrouds
• Airframe skin
• Desalination
• Chemical processing
• Chlorate manufacturing

Grade 4

Grade 4 is known as the strongest of the four grades of commercially pure titanium. It is also known for its excellent corrosion resistance, good formability and weldability.

Though it is normally used in the following industrial applications, Grade 4 has recently found a niche as a medical grade titanium. It is needed in applications in which high strength is required:

• Airframe components
• Cryogenic vessels
• Heat exchangers
• CPI equipment
• Condenser tubing
• Surgical hardware
• Pickling baskets

Grade 7

Grade 7 is mechanically and physically equivalent to Grade 2, except with the addition of the interstitial element palladium, making it an alloy. Grade 7 possesses excellent weldability and fabricality, and is the most corrosion resistance of all titanium alloys. In fact, it is most resistant to corrosion in reducing acids.

Grade 7 is used in chemical processes and production equipment components.

Grade 11

Grade 11 is very similar to Grade 1, except for the addition of a tiny bit of palladium to enhance corrosion resistance, making it an alloy. This corrosion resistance is useful to protect against crevice erosion and reducing acid in chloride environments.

Other useful properties include optimum ductility, cold formability, useful strength, impact toughness and excellent weldability. This alloy can be used in the same titanium applications as Grade 1, especially where corrosion is a concern such as:

• Chemical processing
• Chlorate manufacturing
• Desalination
• Marine applications

Ti 6Al-4V (Grade 5)

Known as the “workhorse” of the titanium alloys, Ti 6Al-4V, or Grade 5 titanium, is the most commonly used of all titanium alloys. It accounts for 50 percent of total titanium usage the world over.

Its usability lies in its many benefits. Ti 6Al-4V may be heat treated to increase its strength. It can be used in welded construction at service temperatures of up to 600° F. This alloy offers its high strength at a light weight, useful formability and high corrosion resistance.

Ti 6AI-4V’s usability makes it the best alloy for use in several industries, like the aerospace, medical, marine and chemical processing industries. It can be used in the creation of such technical things as:

• Aircraft turbines
• Engine components
• Aircraft structural components
• Aerospace fasteners
• High-performance automatic parts
• Marine applications
• Sports equipments

Ti 6AL-4V ELI (Grade 23)

Ti 6AL-4V ELI, or Grade 23, is the higher purity version of Ti 6Al-4V. It can be made into coils, strands, wires or flat wires. It’s the top choice for any sort of situation where a combination of high strength, light weight, good corrosion resistance and high toughness are required. It has a superior damage tolerance to other alloys.

These benefits make Grade 23 the ultimate dental and medical titanium grade. It can be used in biomedical applications such as implantable components due to its biocompatibility, good fatigue strength and low modulus. It can also be used in detailed surgical procedures, as:

• Orthopedic pins and screws
• Orthopedic cables
• Ligature clips
• Surgical staples
• Springs
• Orthodontic appliances
• In joint replacements
• Cryogenic vessels
• Bone fixation devices

Grade 12

Grade 12 titanium holds an “excellent” rating for its high quality weldability. It is a highly durable alloy that provides a lot of strength at high temperatures. Grade 12 titanium possesses characteristics similar to 300 series stainless steels.

This alloy can be hot or cold formed using press brake forming, hydro press forming, stretch forming or drop hammer method. Its ability to be formed in a variety of ways makes it useful in many applications. This alloy’s high corrosion resistance also makes it invaluable to those manufacturing equipment where crevice corrosion is a concern. Grade 12 can be used in the following industries and applications:

• Shell and heat exchangers
• Hydrometallurgical applications
• Elevated temperature chemical manufacturing
• Marine and airfare components

Ti 5Al-2.5Sn

Ti 5Al-2.5Sn is a non-heat treatable alloy that can achieve good weldability with stability. It also possesses high temperature stability, high strength, good corrosion resistance and good creep resistance. Creep refers to the phenomenon of plastic strain over long periods of time, which happens at high temperatures.

Ti 5Al-2.5Sn is mostly used in aircraft and airframe applications, as well as cryogenic applications.

Virwadia Steels is a supplier, manufacturer, and exporter of various metal products, including titanium. They supply titanium directly to their customers, so you would not need a separate third-party supplier.

Titanium Grades and Forms

Virwadia Steels offers a range of titanium products in various grades and forms. They specialize in both commercially pure titanium and titanium alloys.

Grades:

• Commercially Pure (CP) Titanium: They offer CP titanium in Grades 1, 2, and 4. These grades are known for their high ductility, excellent corrosion resistance, and good formability.

• Titanium Alloys: They supply Grade 5 (Ti-6Al-4V), which is the most widely used titanium alloy due to its exceptional strength-to-weight ratio and corrosion resistance. They also offer Grade 7 (Ti-0.15Pd) and Grade 12 (Ti-0.3Mo-0.8Ni), which are known for their enhanced corrosion resistance in reducing acids.

Forms and Sizes:

Virwadia Steels supplies titanium in multiple forms and can provide custom sizes to meet specific project needs. The standard forms available include:

• Rods and Round Bars: Available in various diameters and lengths, including single-piece lengths up to 6 meters.

• Sheets and Plates: Offered in different thicknesses, from thin foils to thick plates, with standard sizes like 1000 x 2000 mm.

• Pipes and Tubes: They provide both seamless and welded pipes and tubes.

• Wires: Available in various diameters, often used for welding and other applications.

• Forgings, Discs, and Rings: Custom-forged shapes can be supplied based on client drawings.

To get specific information on pricing, lead times, and available stock for a particular grade, size, or form, it is best to contact Virwadia Steels directly.Virwadia Steels, which also operates as Virwadia Metal & Alloys, is a direct supplier of titanium products. You would not need a separate third-party supplier as they provide a range of titanium grades and forms themselves.

Titanium Grades and Forms

Virwadia Steels offers both commercially pure titanium and titanium alloys, catering to a variety of industrial applications. They can also provide custom sizing and fabrication.

• Commercially Pure (CP) Titanium: They supply Grades 1, 2, and 4. These are valued for their excellent corrosion resistance, especially in marine and chemical environments, and their good formability. Grade 2 is the most commonly used CP grade due to its balance of strength, ductility, and weldability.

• Titanium Alloys: They are a known supplier of Grade 5 (Ti-6Al-4V), the most widely used titanium alloy globally. This grade is prized for its high strength-to-weight ratio and is commonly used in aerospace and medical applications. They also offer Grades 7 and 12, which have superior corrosion resistance, particularly in reducing acids.

Available Product Forms

Virwadia Steels stocks and supplies titanium in a number of standard forms, with the ability to provide custom cuts and finishes.

• Sheets, Plates & Coils: Available in a range of thicknesses and standard dimensions, as well as coils for continuous processing.

• Rods & Bars: Offered in both round and flat bar configurations, with single-piece lengths up to 6 meters.

• Pipes & Tubes: Both seamless and welded pipes are available.

• Wires, Forgings & Rings: They can also provide titanium in these specialized forms for various industrial applications.

To inquire about specific sizes, certifications, and current stock for your project, it is best to contact us directly at [email protected]
